Supports customization with a processing capacity of up to 15900 CFM (cubic feet per minute).
The 200 CFM refrigerated air dryer (air cooled) is a compact and efficient solution for removing moisture from compressed air systems. Designed for mid-sized industrial applications, this dryer ensures clean, dry air to protect downstream equipment from corrosion, contamination, and failure.
With air-cooled technology and stable dew point performance, the 200 CFM refrigerated air dryer (air cooled) offers a reliable and energy-saving approach to compressed air drying.
✅ Rated for 200 CFM: Optimized to handle air flow rates up to 200 CFM, ideal for medium-scale operations.
✅ Air Cooled Condenser: No need for cooling water — suitable for flexible installation in any plant environment.
✅ Stable Dew Point: Maintains a consistent pressure dew point between 2–10°C (35.6–50°F).
✅ Efficient Heat Exchanger: Maximizes moisture separation while minimizing pressure loss.
✅ Energy Efficient: Designed to reduce power consumption with high-performance components.
✅ Automatic Drain System: Prevents water accumulation and extends system life.
✅ Compact Design: Space-saving footprint for easy integration into existing systems.
The 200 CFM refrigerated air dryer (air cooled) combines durability and performance to meet the demands of modern compressed air systems.
Inlet Air Temperature: ≤ 45°C (113°F)
Ambient Temperature: 5 – 45°C (41 – 113°F)
Installation Location: Indoor, clean and well-ventilated environment
Power Supply: 220V / 1Ph / 50Hz (custom options available)
Refrigerant Type: R134a or R410A (environmentally friendly refrigerants)
Filtration Advice: Pre-filters and after-filters recommended for best air quality
| Model | 200 CFM Refrigerated Air Dryer (Air Cooled) |
|---|---|
| Air Capacity | 200 CFM (Cubic Feet per Minute) |
| Cooling Type | Air Cooled |
| Refrigerant | R134a / R410A |
| Max Pressure | 10 bar |
| Pressure Dew Point | 2 – 10°C |
| Power Supply | 220V / 1Ph / 50Hz |
| Connection Size | 1¼” NPT |
| Dimensions (L×W×H) | 850 × 500 × 900 mm |
| Weight | 95 kg |
The 200 CFM refrigerated air dryer (air cooled) is engineered for easy installation, consistent performance, and long service life.
In India’s hot climate, seasonal monsoon humidity, and busy factory environments, compressed air systems often face increased moisture load that can affect pneumatic equipment, production stability, and finished product quality. The 200 CFM refrigerated air dryer (air cooled) is designed for medium-scale compressed air systems that require reliable day-to-day moisture removal, easy installation, and stable general-purpose dry air. With a pressure dew point of 2–10°C, it is well suited for indoor industrial applications where condensate control and consistent compressed air quality are essential.
This refrigerated dryer is intended for general industrial moisture removal, not ultra-low dew point applications. For Indian users in high-humidity or monsoon-affected regions, indoor installation in a clean, well-ventilated environment, together with recommended pre-filters and after-filters, will help maintain stable performance. For applications that require very dry air, such as critical process air or dew points below 0°C, an adsorption dryer may be more appropriate.
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
This 75 CFM (air-cooled) refrigerated air dryer is a reliable and energy-efficient solution, specifically designed to remove moisture from compressed air systems. It is ideal for small to medium industrial applications, providing clean, dry compressed air with a stable pressure dew point. With its compact design and air-cooled operation, this 75 CFM (air-cooled) refrigerated air dryer ensures long-term, stable performance while minimizing maintenance requirements.
Whether you operate a workshop, packaging line, or small production facility, the 75 CFM refrigerated air dryer (air-cooled) is the perfect choice to protect your pneumatic tools and equipment from moisture-related issues.
The 25/35/50 CFM Air-Cooled Refrigerated Air Dryer from Lingyu is a compact and energy-efficient solution for small to medium compressed air systems. It efficiently removes moisture and maintains a stable dew point, providing clean, dry air for tools, machinery, and production processes.
With its reliable air-cooled design, low power consumption, and easy operation, this dryer series helps improve air system performance, reduce maintenance costs, and protect equipment from moisture-related damage.
The 1130 SCFM refrigerated air dryer (air cooled) is a high-capacity, energy-efficient solution designed to eliminate moisture from compressed air systems in demanding industrial environments. With a robust air-cooled refrigeration system and a processing capacity of 1130 SCFM, this dryer delivers consistent performance and reliable dew point control to protect downstream equipment and ensure production continuity.
Whether you’re operating in a manufacturing plant, automotive facility, or heavy-duty processing site, the 1130 SCFM refrigerated air dryer (air cooled) guarantees optimal air quality while reducing maintenance costs and energy waste.
Good treatment effect: equipped with an independent water distribution system and it is a multiple upgraded version, the water distribution efficiency is guaranteed;
Wide application conditions: hydrophilic aluminum foil is used, and the whole series is equipped with heat exchangers and pre-coolers as standard, which can better adapt to harsh working conditions
Wide application conditions: hydrophilic aluminum foil is used, and the whole series is equipped with heat exchangers and pre-coolers as standard, which can better adapt to harsh working conditions
Customized according to needs: color can be customized, PLC is optional, dry contacts, Modbus communication, Internet of Things communication, etc. can be customized according to customer needs
