Supports customization with a processing capacity of up to 17660 CFM (cubic feet per minute).
The Blower & Zero Purge Adsorption Dryer is an advanced solution for industrial compressed air systems, designed to provide continuous, energy-efficient moisture removal.
This dryer combines blower-assisted regeneration with a zero purge cycle, ensuring the regeneration process consumes no compressed air. Ambient air is drawn in by the blower, heated to desorb moisture from the adsorbent, and then cooled through an intermediate cooler in a continuous closed-loop cycle. The result is a stable low dew point with minimal energy usage, protecting downstream equipment and ensuring consistent air quality in industrial operations.
The Blower & Zero Purge Adsorption Dryer is designed to deliver continuous, energy-efficient moisture removal for industrial compressed air systems. Unlike conventional adsorption dryers that consume compressed air during regeneration, this system uses blower-assisted heated regeneration with zero purge, which means no compressed air is used in the regeneration process.
During operation, ambient air is drawn in by a blower and heated before passing through the saturated adsorption tower to desorb moisture from the adsorbent. The regeneration air is then cooled through an intermediate cooler, creating a stable and efficient regeneration cycle. By alternating between adsorption and regeneration, the dryer maintains a continuous supply of dry compressed air with a stable low dew point while significantly reducing operating costs.
This advanced design combines zero compressed air consumption, blower-assisted regeneration, and intermediate cooling, making it an ideal solution for industrial users who require reliable drying performance, long-duty operation, and improved energy efficiency.
To ensure stable performance and efficient operation, the Blower & Zero Purge Adsorption Dryer should be used under the following recommended conditions:
For the best drying effect and longer adsorbent service life, the dryer should be installed with proper pre-filtration and operated under stable inlet conditions. This helps protect downstream equipment, maintain consistent air quality, and improve long-term system reliability.
| Model | Capacity (m³/min) | Gas Connection Pipe | Power (kW) | Dimensions (mm) |
|---|---|---|---|---|
| HRB-Z100 | 13.5 | DN50 | 7.5 | 1390×970×2297 |
| HRB-Z120 | 17 | DN65 | 10.2 | 1750×1050×2271 |
| HRB-Z150 | 21.5 | DN80 | 11.8 | 1750×1050×2471 |
| HRB-Z180 | 25 | DN80 | 14.2 | 1800×1050×2597 |
| HRB-Z200 | 28.5 | DN80 | 16.8 | 1900×1100×2454 |
| HRB-Z250 | 32 | DN80 | 18.4 | 1920×1260×2600 |
| HRB-Z300 | 37 | DN100 | 21.5 | 2175×1340×2750 |
| HRB-Z350 | 41.5 | DN100 | 25.9 | 2200×1350×2752 |
| HRB-Z400 | 45 | DN100 | 27.5 | 2400×1500×2852 |
| HRB-Z450 | 50 | DN100 | 30 | 2540×1670×2938 |
| HRB-Z500 | 55 | DN125 | 31.5 | 2650×1700×3138 |
| HRB-Z550 | 60 | DN125 | 33.5 | 2700×1840×3150 |
| HRB-Z600 | 65 | DN125 | 36.3 | 2750×1840×2888 |
| HRB-Z700 | 75 | DN125 | 41.1 | 2750×1840×2888 |
| HRB-Z800 | 85 | DN125 | 47.8 | 3100×1900×3050 |
| HRB-Z900 | 95 | DN150 | 52.6 | 3250×2100×2950 |
| HRB-Z1000 | 110 | DN150 | 59 | 3250×2100×2950 |
| HRB-Z1200 | 120 | DN150 | 63.8 | 3500×2200×3341 |
| HRB-Z1400 | 140 | DN200 | 74.1 | 3700×2400×3420 |
| HRB-Z1600 | 160 | DN200 | 89 | 3900×2420×3500 |
| HRB-Z1800 | 180 | DN200 | 98.5 | 4100×2200×3050 |
| HRB-Z2100 | 210 | DN200 | 110.5 | 4200×2835×3150 |
| HRB-Z2600 | 260 | DN250 | 136.4 | 5200×2500×3300 |
Note：For air volumes above 260 m³/min or special specifications (materials, temperature, or pressure), please contact our company or authorized dealers. Data is for reference only and may change without prior notice.
In India’s hot climate, seasonal monsoon humidity, and high-load industrial environments, compressed air systems often require dependable low-dew-point drying with strong operating efficiency. The Blower & Zero Purge Adsorption Dryer is designed for large compressed air systems that need continuous dry air, stable performance, and lower long-term operating cost by eliminating compressed air loss during regeneration. With optional outlet pressure dew points of -20°C or -40°C and 0% regeneration gas consumption, it is well suited for Indian industrial users operating large plant air systems in moisture-sensitive and energy-conscious applications.
For the India page, this model is best positioned as an energy-efficient low-dew-point drying solution for large industrial air systems, rather than a small workshop dryer. It is especially suitable for large manufacturing plants, electronics production, pharmaceutical support areas, food packaging, chemical processing, textile operations, and centralized factory air stations where continuous operation and compressed air savings matter. Because India’s climate includes hot pre-monsoon conditions and a humid monsoon season, the page should also emphasize proper pre-filtration, stable inlet conditions, and suitable cooling-water support to maintain drying efficiency and long-term adsorbent performance.
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
The independently developed EBZ200-2 multi-core driver can save more than 10% of the comprehensive energy consumption compared with the fixed cycle mode;
The communication can meet the user's requirements such as RS-485 (standard), IoT connection, etc.
The optional dew point energy-saving control can extend the adsorption time and reduce the comprehensive energy consumption by more than 30% under load fluctuation conditions;
Customized high-performance adsorbent, 20% filling margin;
304 stainless steel control gas pipeline, specially designed diverter, high adsorbent utilization rate, small gas pressure loss;
7-inch Siemens touch screen programmable controller, dynamic monitoring of operation process；
The communication can meet the user's requirements such as RS-485 (standard), IoT connection, etc.
The independently developed EBZ200-2 multi-core driver can save more than 10% of the comprehensive energy consumption compared with the fixed cycle mode;
The optional dew point energy-saving control can extend the adsorption time and reduce the comprehensive energy consumption by more than 30% under load fluctuation conditions;
Customized high-performance adsorbent, 20% filling margin;
304 stainless steel control gas pipeline, specially designed diverter, high adsorbent utilization rate, small gas pressure loss;
7-inch Siemens touch screen programmable controller, dynamic monitoring of operation process；
