High-quality shell material,exquisite appearance design,sophisticated threadprocessing technology;
The differential pressure gauge indicates thetimeto replace thefiter elementat a glance;
The exterior is sprayed withepoxy resin powder to improve durabiityand corrosionresistance;
The casingls marked withthe airflow direction,and thefiter tube head and tubebodyare connected by bayonetypefor easy and quickinstallation andmaintenance;
The flow path is enlargedto reduce pressuredropyReliable automatic draining device;
Using imported filtermaterial,thefiltration accuracy is high.
Our high-performance compressed air filters provide precise particle removal and ultra-low residual oil content for industrial and laboratory applications. Designed for different levels of air purification, these filters ensure clean, dry, and oil-free compressed air, improving the performance and longevity of downstream equipment.
| Grade | Particle Removal | Residual Oil Content |
|---|---|---|
| AO Grade | ≤ 1.0 μm | ≤ 3.0 ppm |
| AX Grade | ≤ 0.01 μm | ≤ 0.05 ppm |
| AA Grade | ≤ 0.1 μm | ≤ 0.1 ppm |
| ACS Grade | ≤ 0.01 μm | ≤ 0.003 ppm |
AO Grade: General industrial air filtration, removes larger particles and oil droplets.
AX Grade: High-purity air filtration for sensitive pneumatic systems.
AA Grade: Fine filtration for precise machinery and instrumentation.
ACS Grade: Ultra-high purity air for critical applications such as electronics, pharmaceuticals, and medical air supply.
ModelCapacity (m³/min)Dimensions (L×W×H mm)Interface DiameterFilter Element ModelYAF-D015AO/AA/AX/ACS1.596×235RC 3/4”(Grade)-015K×1LYAF-D024AO/AA/AX/ACS2.596×235RC 1”(Grade)-024K×1LYAF-D035AO/AA/AX/ACS3.840×310RC 1 1/2”(Grade)-035K×1YAF-D060AO/AA/AX/ACS6.540×410RC 1 1/2”(Grade)-060K×1LYAF-D090AO/AA/AX/ACS10.575×530C 2”(Grade)-090K×1YAF-D120AO/AA/AX/ACS13.575×530RC 2 1/2”(Grade)-120K×1LYAF-D150AO/AA/AX/ACS1775×815RC 2 1/2”(Grade)-150K×1LMAF-D220AO/AA/AX/ACS22240×724RC 3”(Grade)-220K×1LVAF-D240AO/AA/AX/ACS28.5240×724RC 3”(Grade)-240K×1
In India’s hot climate, seasonal monsoon humidity, and demanding industrial environments, compressed air systems often require staged filtration to remove particles, oil aerosols, and residual contaminants before air reaches downstream equipment. Lingyu compressed air filters are designed to support different levels of air purity, from general industrial protection to high-purity air treatment for sensitive processes. They are well suited for Indian factories and facilities that need cleaner, more reliable compressed air in both standard and critical applications.
For Indian installations, compressed air filters are best used as part of a complete air treatment system that may include pre-filtration, refrigerated or adsorption drying, and final fine filtration, depending on the required air quality level. In high-humidity regions or during monsoon conditions, correct filter grade selection and regular element replacement are especially important for maintaining stable performance.
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
